Reduce Head Half Hex Body Steel 1

0
View: 580

Details:



UNIT:mm

R=Reduce/H=Halfl hex/S=Steel

Thread

Number
P/N

T(GRIP RANGE)
MIN MAX

A
Ref

Hole Size
+0.1
0

D
+0.07
-0.1

HB
土 0.30

K
土0.15

L
土 0.30

M3

RHS-03M-15B

0.5-1.5

5.2

5.0

4.9

5.8

0.5

8.5

M4

RHS-04M-20B

0.5-2.0

8.3

6.0

5.9

7.0

0.5

12.0

M5

RHS-05M-25B

0.5-2.5

9.0

7.0

6.9

8.0

0.5

13.0

M6

RHS-06M-35B

1.0-3.5

10.5

9.0

8.9

10.0

0.6

16.0

M8

RHS-08M-35B

1.0-3.5

11.3

11.0

10.9

12.0

0.7

17.5

M10

RHS-10M-40B

1.0-4.0

13.5

13.0

12.9

14.5

0.8

21.0

M12

RHS-12M-40B

1.5-4.0

15.5

16.0

15.9

17.0

1.0

24.0

All close end pants number add "B", AS:RHS-O4MF-30B
